| Size | Range | Tables | Casting Type |
|---|---|---|---|
| 50mm | Ø69 → Ø71 | D/E/ANSI | SAND |
| 75mm | Ø100 → Ø104 | D/E/ANSI | GRAVITY |
| 100mm | Ø125 → Ø129 | D/E/ANSI | GRAVITY (D) SAND (E/ANSI) |
| 125mm | Ø152 → Ø157 | D/E | SAND |
| 150mm | Ø181 → Ø185 | D/E/ANSI | GRAVITY (D) SAND (E/ANSI) |
| 200mm | Ø233 → Ø238 | D/E/ANSI | GRAVITY (D) SAND (E/ANSI) |
| 250mm | Ø285 → Ø289 | D/E/ANSI | SAND |
| 300mm | Ø340 → Ø345 | D/E/ANSI | SAND |
| 350mm | Ø395 → Ø405 | D/E/ANSI | SAND |
| 400mm | Ø454 → Ø461 | ANSI | SAND |
Aluminium Tables D, E, ANSI150 Muff Coupling
High strength gravity & sand cast aluminium at a greatly reduced price compared to sand. Our 3″ to 8″ gravity casting muff couplings offers a higher amount of strength when compared to the same alloy cast in sand. As well we have greater precision consistency to the OD of the hose due to the coupling being made in an iron permanent mould rather than from an inconsistent sand pattern.
To suit Table D, E & ANSI. We also have elongated the bolt holes allow for more flexibility when fitting. Please see below table for complete range details.
Please contact me at sales@alcast.com.au for trade pricing.
| Coupling Sizes | 3" (75mm), 4" (100mm), 6" (150mm), 8" (200mm), 10" (250mm), 12" (300mm) |
|---|
